LiNbO3 Crystals and Components

Lithium niobate is a ferroelectric material suitable for a variety of applications. Its versatility is made possible by the excellent electro-optic, nonlinear, and piezoelectric properties of the intrinsic material. It is one of the most thoroughly characterized electro-optic materials, and crystal growing techniques consistently produce large crystals of high perfection.

Applications that utilize the large electro-optic coefficients of lithium niobate are optical modulation and Q-switching of infrared wavelengths. Because the crystal is nonhygroscopic and has a low half-wave voltage, it is often the material of choice for Q-switches in military applications. The crystal can be operated in a Q-switch configuration with zero residual birefringence and with an electric field that is transverse to the direction of light propagation. Because piezoelectric ringing can be severe, piezoelectrically damped designs can be very useful. The damage threshold of the intrinsic material at 1.06 microns with a 10 nsec pulse is approximately 3 J/cm2. With appropriate AR coatings, a surface damage threshold of 300-500 MW/cm2 can be achieved for the same conditions.

Applications that use the large nonlinear d coefficient of LiNbO3 include optical parametric oscillaton, difference frequency mixing to generate tunable infrared wavelengths, and second harmonic generation. With a broad spectral transmission, which ranges from 0.4 µm to 5.0 µm with an OH- absorption at 2.87 µm, a large negative birefringence, and a large nonlinear coefficient, phasematching is an effective way to generate tunable wavelengths over a broad wavelength range.

Lithium niobate is particularly effective for second harmonic generation of low power laser diodes in the 1.3 to 1.55 µm range.

For infrared generation by difference frequency mixing, the peak power limit is considerably lower than for 1.064 µm, being about 40 MW/cm2Efficiencies for difference frequency mixing generally are smaller than shg efficicncies with KDP or BBO, which is due to the lower peak powers that can be tolerated by the crystal and the fact that the longer wavelength photons that are generated in the process are less energetic. Typical powers for 10 nanosecond long pulses with 5 mm diameter beams are 30 mJ/pulse of 0.640 µm minus 40 mJ/pulse of 1.064 µm to produce 2.5 mJ/pulse at 1.54 µm, and 32 mJ/pulse of 0.532 µm minus 32 mJ/pulse of 0.640 µm to produce 0.25 mJ/pulse at 3.42 µm.

ULTI Crystals general capabilities include providing high quality and large size LiNbO 3 crystal for quasi-phase-matched doublers and waveguide substrate and SAW wafers.

Details Information   Characteristic data
»| Physical and Optical Properties
»|
Standard Processing Specifications
»| Notes Related Pages
»| Download PDF documents pdf


Standard Product List
LiNbO3 Box:
Code
Dimension(mm)
Applications
coating
Price
LNB-101
5x5x20
SHG or OPO
AR/AR@1550nm
Contact us
LNB-102
8x8x20
SHG or OPO
AR/AR@1550nm
Contact us
LNB-103
9x9x25
SHG or OPO
AR/AR@1550nm
Contact us
LNB-104
10x10x25
SHG or OPO
AR/AR@1550nm
Contact us
LiNbO3 Wedge:
Code
X(mm)
Y(mm)
Z(mm)
θ
φ
coating
Price
LNW-101
0.25
1.25
1.25
13°
22.5°
AR/AR@1550nm
Contact us
LNW-102
0.25
1.25
1.25
15°
22.5°
AR/AR@1550nm
Contact us
LNW-103
0.25
1.25
1.25
13°
22.5°
AR/AR@1310nm
Contact us
LNW-104
0.25
1.25
1.25
15°
22.5°
AR/AR@1310nm
Contact us

Notes
  »| Custom size is available upon requested.
